2D Barcode Scanner
TBS-6624
Thermix TBS-6624
Plug-and-play 2D CMOS handheld scanner for paper and screen barcodes
Key Features
- Scans 1D and 2D barcodes on paper and screens
- Dual-mode indication — LED light & buzzer
- Plug and play — no driver design required
- High-strength material, shock-proof and fall-proof
The Thermix TBS-6624 reads 1D and 2D barcodes on paper and screens with a CMOS image sensor, dual LED/buzzer feedback, and true plug-and-play setup. High-strength ABS+PC construction is shock-proof and fall-proof for daily retail and restaurant use.
USB-HID, USB-COM, and RS232 interfaces plus a 1.5 m cable make it ready for most POS terminals without extra software.
Specifications
Technical data from the official Thermix TBS-6624 datasheet.
| Light Source | Red LED aimer, white LED illumination |
|---|---|
| Image Sensor | CMOS 640 × 480 |
| Field of View | Horizontal 32°, Vertical 24° |
| Scan Mode | Manual / Continuous / Auto-inductive |
| Scan Angle | Skew ±60°, Roll 360°, Pitch ±60° |
| Precision | ≥ 4 mil |
| Contrast | ≥ 20% |
| Bit Error Rate | < 1/5 million |
| Decode 1D | EAN, UPC, Code 128/39/93, Codabar, Interleaved 2 of 5, GS1 Databar, and more |
| Decode 2D | QR Code, PDF417, Data Matrix, Aztec, Han-Xin, MaxiCode, Micro QR |
| Depth of Field | EAN-13 40–240 mm; QR 30–180 mm |
| Interface | USB-HID, USB-COM, RS232 |
| Dimensions | 64 × 84 × 152 mm |
| Weight | 137 g |
| Material | ABS + PC |
| Cable | 1.5 m |
| Voltage | DC 5V ± 5% |
| Working Current | 170 mA |
| Drop Resistance | Multiple 1.5 m drops to concrete |
| Operating Temp | -20°C – 50°C |
